Technical description
Rectangular shower tray made of Marbond (Gel Coat surface matt, with structure) with Antislip, Class C (DIN 51097).
Removable siphon cover, Marbond For floor-even installation or on floor installation.
Mounting accesories excluded
Linear siphon for Laufen Pro S shower trays with water trap height of 30 mm, order no. H290182 with water trap height of 50 mm, order no. H290183
Installation frame, adjustable height between 85-160 mm, order no. H298442
Antinoise set for the frame installation to fulfil.
DIN 4109 and SIA 181, order no. H298989
3-D sealing tape: Sealing set 3,0 m, for sealed sides ≤ 3 m, includes 1 sealing tape (width 120 mm, length 3 m), 3-D inside corner for sealing (1 piece) and 2x 3 rm antinoise tape (width 30 mm), order no. H295642
Additional sealing set 2,0 m, for sealed sides ≥ 3 m, order no. H295647
3-D sealing corners: inside corner, 1 piece, order no. H295643, outside corner for floor-even installation, set 3 parts, order no. H295644
Dispersion sealing composition, tube 500 ml, order no. H295645
Noise control band, order no. H295551
Depth:
Superslim (less than 45mm)
Installation type:
Built-in, Corner
Material:
Marbond
Net weight (kg):
52.65
Option:
standard option
Shape:
Rectangular
MATERIAL
Marbond is a composite material made of two layers which are extremely well connected with each other: The basis is formed by a high-quality mineral casting material, the surface is coated with a two millimetre thick acrylic layer. Marbond is hygienic, easy to clean, temperature resistant according to EN 263 and anti-slip (class C).
Compatible products
Similar products
Shower tray, made of Marbond composite material, rectangular, linear outlet at short side, made-to-measure
Article-No.: H2111870000001
Shower tray, made of Marbond composite material, square, linear outlet at short side
Article-No.: H2101800000001
900 x 900 x 28
Shower tray, made of Marbond composite material, rectangular, linear outlet at short side
Article-No.: H2101860000001
1000 x 900 x 28
Shower tray, made of Marbond composite material, square, linear outlet at short side
Article-No.: H2111890000001
1000 x 1000 x 30
Shower tray, made of Marbond composite material, rectangular, linear outlet at short side
Article-No.: H2101870000001
1200 x 900 x 30
Shower tray, made of Marbond composite material, rectangular, linear outlet at short side
Article-No.: H2121800000001
1200 x 1000 x 30
Shower tray, made of Marbond composite material, square, linear outlet at short side
Article-No.: H2121830000001
1200 x 1200 x 30
Shower tray, made of Marbond composite material, rectangular, linear outlet at short side
Article-No.: H2111830000001
1300 x 900 x 32
PRO S
With great sensitivity, designer Peter Wirz of Vetica Design has evolved the LAUFEN PRO concept into a slimmer, more geometric form. Defined by precise radii and a light silhouette, LAUFEN PRO S unites elegance with everyday functionality, bringing premium design within reach while combining effortlessly with existing pieces from the LAUFEN PRO collection.
