Technical description
Floorstanding WC pan washdown LAUFEN PRO, sanitary ceramic, for cistern, EN 997, EN 33, 6/3-l-flush, dimensions 360 x 700 x 480 mm, outlet horizontal, VARIO vertical 70 - 305 mm, back to wall, concealed fixation, lenght 700 mm, ceramic height 460 mm, 2 fixing holes, Special feature: concealed surfaces directing water are fully glazed, throughout, closed water rim, vacuum checked, Further options / accessories: Surface refinement LCC (only white), 4 fixing holes, 2 fixing holes and lateral holes, cistern 82695.0, 82695.2, 82695.3, 82695.5, WC seat 89295.0, 89395.4, WC seat and cover, 89195.0, 89295.1, 89395.2, WC seat and cover with automatic lowering, 89195.1, 89395.3, Order no. 82495.5
Mounting accesories included
Charge 000/231 – 1x Fixing set,Charge 204 – 2x Fixing set, order no. 89175.7
Average water consumption (L.):
3.72
Back-to-wall
Comfort height
Fixing kit:
Included
Flushing system:
Washdown
Installation type:
Floor-standing
Net weight (kg):
32.8
Option:
standard option
Outlet type:
Dual
Rim type:
Open
Shape:
Round
Style:
Neutral
Unified Water Label
3.72 l
